GE models are designed to be the quietest PTAC’s on the market. Manufactured with an extra seal around the edge that keeps excess noise and dirt outside, a heavy-duty mastic barrier to provide additional noise reduction and two DC fan motors for quiet operation, independent third-party testing confirms the GE Zoneline is the quietest PTAC against leading competitors.
- Zoneline models are reliable, quiet, efficient and have an updated, streamlined appearance
- A simplified structure makes GE models easy to maintain and service
- Smart Fan Cooling/Heating allows the fan to run in either continuous mode during hot weather or cycle mode during the winter months – saving energy and improving comfort
- Special Premium Guard Corrosion Protection keep each part performing at peak condition
- Zoneline models have integrated structural components for easy maintenance and support
- Rustproof base pan, a GE signature durable design feature, comes standard on all models
- A service diagnostics port allows technicians to quickly diagnose problems
- With Quick Connect, the thermostat, central desk control and external fan can be connected in seconds for faster installation and servicing
ELECTRIC HEAT
AZ45E07DAB
Voltage: 230/208
BTU: 7,200/7,000
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E07DAC
Voltage: 230/208
BTU: 7,300/7,000
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E07DAP
Voltage: 230/208
BTU: 6,900/6,800
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E07EAC
Voltage: 265
BTU: 7,300
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E09DAB
Voltage: 230/208
BTU: 9,700/9,600
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E09DAC
Voltage: 230/208
BTU: 9,400/9,300
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E09DAP
Voltage: 230/208
BTU: 9,400/9,300
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E09EAC
Voltage: 265
BTU: 9,500
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E09EAP
Voltage: 265
BTU: 9,500
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E12DAB
Voltage: 230/208
BTU: 11,900/11,800
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E12DAC
Voltage: 230/208
BTU: 11,800/11,600
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E12DAP
Voltage: 230/208
BTU: 11,200/11,100
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E12EAC
Voltage: 265
BTU: 11,800
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E12EAP
Voltage: 265
BTU: 11,000
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E15DAB
Voltage: 230/208
BTU: 14,900/14,800
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E15DAC
Voltage: 230/208
BTU: 14,600/14,500
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
AZ45E15EAC
Voltage: 265
BTU: 14,900
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Electric Heat
Need Zoneline Accessories? Allied Carries The Full Line!
Zoneline Sleeve (RAB81)
Click Here for Product Sheet
Zoneline Grille (RAG60)
Click Here for Product Sheet
Zoneline Drain Kit (RAD10)
Click Here for Product Sheet
Zoneline Standard Thermostat (RAK149F2)
Click Here for Product Sheet
Zoneline Energy Management
Wired or Wireless (RAK180W1)
Click Here for Product Sheet
HEAT PUMP
AZ65H07DAB
Voltage: 230/208
BTU: 7,100/6,900
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H07DAC
Voltage: 230/208
BTU: 7,100/6,900
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H07DAD
Voltage: 230/208
BTU: 7,000/6,900
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H07EAC
Voltage: 265
BTU: 7,000
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H07EAD
Voltage: 265
BTU: 7,000
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H09DAB
Voltage: 230/208
BTU: 9,700/9,600
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H09DAC
Voltage: 230/208
BTU: 9,700/9,600
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H09DAD
Voltage: 230/208
BTU: 9,600/9,500
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H09EAC
Voltage: 265
BTU: 9,500
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H09EAD
Voltage: 265
BTU: 9,500
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H12DAB
Voltage: 230/208
BTU: 12,100/11,900
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H12DAC
Voltage: 230/208
BTU: 11,900/11,800
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H12DAD
Voltage: 230/208
BTU: 11,800/11,600
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H012EAC
Voltage: 265
BTU: 11,900
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H12EAD
Voltage: 265
BTU: 11,900
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H15DAB
Voltage: 230/208
BTU: 14,400/14,200
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H15DAC
Voltage: 230/208
BTU: 14,500/14,200
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H015DAD
Voltage: 230/208
BTU: 14,300/14,100
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H15EAC
Voltage: 265
BTU: 14,500
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
AZ65H15EAD
Voltage: 265
BTU: 14,300
AMPS: 15/20/30
HEAT PUMP/ELECTRIC HEAT: Heat Pump
Need More Information On How To Take Advantage Of Zoneline's Incredible Features? Watch one of GE's How To Videos.
Playlist
Need more information. Click here to access the AZ45 and AZ65 Owner’s Manual.
