Amana’s core philosophy is to provide customers with high-quality products that are reliable, meet their needs and last longer than the rest. The Amana brand Packaged Terminal Air Conditioner (PTAC) is designed to provide quiet comfort and operation for hotels, hospitality properties and assisted living/senior facilities. Their acoustically engineered system enhancements include indoor tangential fan for quiet and even air distribution and a two-speed indoor motor for enhanced guest comfort. Additionally, the two-speed outdoor fan allows for lower overall sound as compared to units without this feature.

Quiet Operation – Redesigned to be one of the industry’s quietest PTACs, it features two fan motors and an indoor tangential fan for quiet operation and optimal air distribution.
Reliable Design – Designed with R-410A and R-32 refrigerant filter drier and high-pressure switch. All Amana PTACs are 100% run-tested at their plant, including leak checks during manufacturing as well as prior to shipment from their warehouse.
Integrated Bluetooth – Using the new Amana mobile app, control your PTAC with the touch of a button. The app simplifies set-up and configuration and features integrated Eden™ connectivity (Eden accessories are sold separately). If the wall thermostat dies, the unit will still maintain the room’s temperature and the PTAC can be controlled from a phone app.
Dehumidification – With increased dehumidification capacity, you can feel comfortable in higher temperatures, helping to reduce cooling costs.
Customization– Unrivaled product customization options, including Make-Up Air, Smart Vent and Economizer, Lighting Control, Seacoast, Hydronic and more. Looking for a Seacoast Protected or Make-Up Air PTAC? We carry those! Request a Quote below and specify what you need.
R32 Refrigerant – R32 is easy to recycle and has a 30% lower GWP than R410A. Like R410A, R32 has a zero ozone depletion potential and is easy to charge and recover. Its increased efficiency over R410A means the air conditioner will use less refrigerant than previous models, thus improving its environmental impact over the life of the product.

Amana PTAC Brochure

We offer FREE SHIPPING on 8+ Units (varies by state and brand) and accept CREDIT CARDS WITH NO SURCHARGE.

Heat/Cool Units
Require 42″ x 16″ Sleeve & Wall Thermostat (sold separately)

12,000 BTU
Model #: PTC123K35AXXX
Electric Heat
Voltage: 208/230 V
Amps: 20 A

12,000 BTU
Model #: PTH123K35AXXX
Heat Pump
Voltage: 208/230 V
Amps: 20 A

DSA02NO
Wireless Thermostat with Backlit Display

Amana PTACs now require a wall thermostat to operate. Touch pad temperature controls will no longer be included and instead the K and J series come factory installed with an antenna to communicate with wall thermostat.

Note: If the wall thermostat dies, the unit will still maintain the rooms temperature and the PTAC can be controlled from an app – this is intended for emergencies only while the wall thermostat is out of service.

Thermostat Overview

Looking for a model with on-board controls? The Distinctions brand is manufactured by the same company that manufactures Amana. Click here to learn more.

First-Year Limited Warranty: First-year parts and labor.

Five-Year Limited Warranty: Second through fifth years includes parts and labor on certain sealed system components, on certain functional parts only.

For complete warranty details, visit www.amana-ptac.com.

Amana Electric Heat PTACs

Heat/Cool Units
Price Drop on Select Units
Require 42″ x 16″ Sleeve & Wall Thermostat (sold separately)

7,000 BTU
Model #: PTC073J35AXXX
Voltage: 208/230 V
BTU: 7,000/7,000
EER: 12.8/12.8 | Amps: 20 A

12,000 BTU
Model #: PTC123J35AXXX
Voltage: 208/230 V
BTU: 11,900/11,700
EER: 11.4/11.5 | Amps: 20 A

9,000 BTU
Model #: PTC093J35AXXX
Voltage: 208/230 V
BTU: 9,200/9,000
EER: 12.1/12.2 | Amps: 20 A

15,000 BTU
Model #: PTC153J50AXXX
Voltage: 208/230 V
BTU: 14,800/14,500
EER: 10.3/10.4 | Amps: 30 A

7,000 BTU
Model #: PTC074J35AXXX
Voltage: 265 V
BTU: 7,000
EER: 13.0 | Amps: 20 A

12,000 BTU
Model #: PTC124J35AXXX
Voltage: 265 V
BTU: 11,800
EER: 11.2 | Amps: 20 A

9,000 BTU
Model #: PTC094J35AXXX
Voltage: 265 V
BTU: 9,200
EER: 11.9 | Amps: 20 A

15,000 BTU
Model #: PTC154J50AXXX
Voltage: 265 V
BTU: 14,800
EER: 10.7 | Amps: 30 A

Amana Heat Pump PTACs

Heat/Cool Units
Price Drop on Select Units
Require 42″ x 16″ Sleeve & Wall Thermostat (sold separately)

7,000 BTU
Model #: PTH073J35AXXX
Voltage: 208/230 V
BTU: 7,100/7,000
EER: 12.4/12.8 | Amps: 20 A
COP: 3.6/3.7

12,000 BTU
Model #: PTH123J35AXXX
Voltage: 208/230 V
BTU: 12,000/11,600
EER: 11.5 | Amps: 20 A
COP” 3.3

9,000 BTU
Model #: PTH093J35AXXX
Voltage: 208/230 V
BTU: 9,000/9,000
EER: 12.4/12.5 | Amps: 20 A
COP: 3.6

15,000 BTU
Model #: PTH153J50AXXX
Voltage: 208/230 V
BTU: 14,600/14,400
EER: 10.4/10.6 | Amps: 30 A
COP: 3.1

7,000 BTU
Model #: PTH074J35AXXX
Voltage: 265 V
BTU: 7,300
EER: 12.5 | Amps: 20 A
COP: 3.5

12,000 BTU
Model #: PTH124J35AXXX
Voltage: 265 V
BTU: 12,000
EER: 11.3 | Amps: 20 A
COP: 3.3

9,000 BTU
Model #: PTH094J35AXXX
Voltage: 265 V
BTU: 9,000
EER: 12.4 | Amps: 20 A
COP: 3.5

15,000 BTU
Model #: PTH154J50AXXX
Voltage: 265 V
BTU: 14,600
EER: 10.4 | Amps: 30 A
COP: 3.0

Amana PTAC Accessories

Model #: WS900QW
Amana Wall Sleeve – Steel Insulated Quiet (White Color)

Model #: SGK01B
Amana Single Pack Stamped Aluminum Grille (Natural Aluminum Color)

Model #: DK900QW
Amana Condensate Drain Kit
(Use with all WS900QW sleeves)

Model #: DSA02NO
Wireless Thermostat with Backlit Display

Model #: PHWT-A150H
Amana Non-Programmable Wired Wall Thermostat

Model #: DS01G
Amana Brand Eden™ Control System – Wireless Thermostat
