Hotpoint PTAC AH11E07D3B

AH11E07D3B

Hotpoint® PTAC with Electric Heat

7000 BTU

20 amps, 230/208 Volt

Hotpoint PTAC Brochure
Category Tags ,

Description

FEATURES

Chassis Type Slide-In
Control Type Electronic
Discharge Grille 2-position
Fan Motor 2
Fan Speed Selections 3 Cooling
3 Fan Only
3 Heating
Heat – Cool Yes
Manual Vent Control Hidden
Rotary Compressor Yes
Unit Features Auto Power Recovery
Automatic Indoor Frost Control
Central Desk Control Compatibility
Freeze Sentinel
Power Cord (LCDI) included
Remote Thermostat Compatibility
Venting Features Concealed Manual Vent Control
Vent Air Filter
Heating System Electric Resistance
Outdoor Vent / Exhaust Yes
Product Type Packaged Terminal Air Conditioners
Refrigerant Type R410A
Temperature Range 61->86 F

CAPACITY

Cooling BTUH (MIN) 7000.0 Btu
Cooling BTUH (MAX) 7200.0 Btu
Cooling EER (BTUH / Watt) 11.9
CFM Indoor Fan High 417
CFM Indoor Fan Medium 405
CFM Indoor Fan Low 382
Heating – Reverse Cycle – BTUH 10900/8900

APPEARANCE

Color Appearance White
Installation Through-the-Wall

WEIGHTS & DIMENSIONS

Approximate Shipping Weight 124 lb
Net Weight 99 lb
Overall Depth 21 in
Overall Height 16 in
Overall Width 42 in

POWER / RATINGS

Cooling – Amperes 2.7/2.9
Cooling – Watts 613/596
Heating – Electric – Heater Watts 3535/2935
Heating – Electric – Heater Amps 15.67/14.26
Voltage (MIN) 208.0 V
Voltage (MAX) 230.0 V

CLAIMS & CERTIFICATIONS

230.0 V

WARRANTY

Parts Warranty Limited 1-year entire appliance
Limited 5-year sealed refrigerating system
Labor Warranty Limited 1-year entire appliance
Limited 5-year sealed refrigerating system
Warranty Notes See written warranty for full details
